Name: Non-woven Abrasive Cloth Flap Disc 5inch
Brand: Wenling Keying Abrasives Co., Ltd.

Non-woven Abrasive Cloth Flap Disc 5inch

non woven abrasive cloth flap disc plate shape ps

Non-woven Abrasive cloth Flap Disc 100 16 c

Non-woven Abrasive cloth Flap Disc 100 16 1

Non-woven Abrasive cloth Flap Disc 100 16 4



The non-woven and abrasive-cloth flaps are stuck to a glass-fabric backing pad, meaning that the discs can be used face-down on large surfaces. Long tool life is achieved through the dense packing of the flaps.

The non woven disc is designed for working on large surfaces with speed-adjustable angle grinders.

 Contact us

Call us +8615067699991

Table of Non-woven Abrasive Cloth Flap Disc 5inch

Non-woven Abrasive Cloth Flap Disc 5inch Non-woven Flap Disc Size Table

Non-woven Abrasive Cloth Flap Disc 5inch Specification:

Diameter: 5 inch=125mm
Max. RPM: 13300 RPM
Raw Materials: Aluminum Oxide(AO), Silicon Carbide(SC)
Grit Size: Coarse-60#/80#, Medium-100#/120#, Fine-150#/180#, Very Fine-240#/320#, Ultra Fine-400#/600#, Micro Fine-800#/1000#
Shank Diameter: 3mm, 6mm, 3.175mm, 6.35mm (Other sizes can be customized)

Non-woven Abrasive Cloth Flap Disc 5inch Materials that can be worked:

Aluminum
Cobalt-based alloys
Other non-ferrous metals
High-temperature-resistant materials
Nickel-based alloys (e. g. Inconel and Hastelloy)
Bronze
Hard non-ferrous metal
Titanium
Titanium alloys
Copper
Soft non-ferrous metal
Brass
Zinc
Stainless steel (INOX)
Thermoplastics
Fiber-reinforced duroplastics (GRP, CRP)
Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)
Steel, cast steel

Non-woven Abrasive Cloth Flap Disc 5inch Applicable Industries

Applications

Roughening
Deburring
Surface work
Cleaning
Structuring (matt finishing, brush matting, and satin finishing)
Fine grinding in multiple steps

Non-woven Abrasive Cloth Flap Disc 5inch Applicable Industries

Safety Warning of Non-woven Abrasive Cloth Flap Disc 5inch

Instructions:

Safety Warning of Non-woven Abrasive Cloth Flap Disc 5inch

Please try to choose an operation indoor environment and wear protective guards and goggles.
Never exceed the recommended maximum permitted rotational speed for safety reasons.
In order to have a good stock removal rate, quality of surface, and thermal loading on the workpiece, the best performance would be with a recommended cutting speed of 15-20m/s.
Don't push and increase the pressure during the processing to achieve a finner surface looking, but try to switch to different grit flap wheels.

Safety Warning:

The clamping length between shank and grinders should be more than 15mm.

Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.
