Silicon Carbide Flap Wheel M14 (SC)

m14 125 7 sc

For general grinding of parts made of aluminum, copper, bronze, titanium and fiber reinforced plastics.

Especially recommended for titanium alloys.

It is very suitable for the aviation industry, especially silicon carbide is the only approved abrasive, such as engine components.

Silicon Carbide Flap Wheel M14 (SC) Grit Size Table Corresponding To Raw Materials

Silicon Carbide Flap Wheel M14 (SC) Grit Size Table Corresponding To Raw Materials


Silicon Carbide Flap Wheel M14 (SC) Specification:

  • Max. RPM: 6120~76300 RPM

  • Other Raw Materials: Aluminum Oxide(AO), Zirconia(ZR), Ceramic Aluminum Oxide Combined (CAO)

  • Grit Size(Silicon Carbide): 120#/180#/240#/320#/400#/600#/800#/1200#/1500#/2000#


Silicon Carbide Flap Wheel M14 (SC) Materials that can be worked:

  • Aluminium

  • Bronze

  • Stone

  • Titanium

  • Titanium alloys

  • Thermoplastics

  • Stainless steel (INOX)

  • Other non-ferrous metals

  • Hard non-ferrous metal

  • Fibre-reinforced duroplastics (GRP, CRP)


Flap Wheels with Shank

Flap wheels with Shank is suitable for grinding small area, dead angle, inner hole surface and slit gaps that difficult to reach. The Features of the abrasive clothes are various with multipurpose application capacity. It is flexible and rich in tensile strength. It could remove the burr and uneven, rough surface with fast grinding force effeciently, meanwhile, can make sure the performance result achieve a slightly finer surface. It is a good product for pre-painting or mirror finishing preparation procedure.


Advantages:

High flexibility to optimium adapation to countours

Steadly high stock removal through the entire tool life and aggressive coated abrasive resin is freed up constantly

The design of opening spaces and flat bonded make the abrasive tools can process as face-down position, so can touch closely to the edges and corners.


Silicon Carbide Flap Wheel M14 (SC) Applications:

  • Leveling

  • Deburring

  • Surface work

  • Weld dressing

  • Fine grinding in multiple steps

  • Structuring (matt finishing, brush matting and satin finishing)

Silicon Carbide Flap Wheel M14 (SC) Applicable Industries

Applicable Industries

■ Chemical processing industries

■ Building

■ Steelworks

■ Tool and mold processing

■ Pipeline

■ Shipping Building

■ Automotive industry

■ Aerospace, gas turbine treatment and repair

■ Machine engineering

Silicon Carbide Flap Wheel M14 (SC) Applicable Industries

Application Purpose

■ Leveling

■ Deburring and Welding grinding

■ Structuring Surfaces

■ Step-by-step fine grinding

Silicon Carbide Flap Wheel M14 (SC) Applicable Industries

Safety Warning of Silicon Carbide Flap Wheel M14 (SC)

Instructions:

Safety Warning of Silicon Carbide Flap Wheel M14 (SC)


Safety Warning:

The clamping length between shank and grinders should be more than 15mm.

Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.

If you have any questions, please contact us immediately
Contact Keying Abrasives Now
Other Flap Wheel M14 Products
Flap Wheel M14 4inch
